Replacement Driveshafts

Ford, Lincoln & Mercury Replacement Driveshafts

Dorman & OE Cross Reference

Description

YI-JEONG Industrial (IJE) in Taichung, Taiwan manufactures 76 replacement driveshafts (propeller shafts) for Ford, Lincoln & Mercury vehicles, including Ford F-150, Ford Expedition, Lincoln Mark LT, Lincoln Navigator, Ford F-350 Super Duty and Ford Explorer. Each IJE part number below is listed with its Dorman interchange number and the OE numbers it replaces, so you can look up any number you already have.

Add Inquiry (0)
Added to Inquiry list.

Ford, Lincoln & Mercury Driveshaft Cross Reference: Dorman and OE Numbers

⬇ Download PDF catalog⬇ Download Excel catalog2026 Driveshaft Catalog – North America · all 686 parts

This page covers 44 1-piece steel shafts, 26 2-piece steel shafts, 2 3-piece steel shafts and 4 aluminum shafts. Lengths are overall lengths from the IJE catalog, shown in millimeters with inch conversion. Tip: press Ctrl+F (Cmd+F on Mac) and type any IJE, Dorman or OE number.

Distributors and importers: send us the IJE, Dorman or OE number to request a quote. Request a quote · Search all makes
IJE No. Type Vehicle Application Position Length Dorman Interchange OE Numbers
IJ1986510 1-Piece Steel Ford Aerostar 1991-1995 Front 1324 mm52.1 in 986-510986510
F79Z-4602-AAF79Z4602AA
F09Z-4602-EF09Z4602E
F19Z4602-AF19Z4602A
IJ1946757 1-Piece Steel Ford Bronco 1985-1987 Rear 753 mm29.6 in 946-757946757
E5TZ4602M
IJ1936894 1-Piece Steel Ford Bronco II 1984-1990 Rear 801 mm31.5 in 936-894936894
E8TZ4602AE
IJ1936895 1-Piece Steel Ford Bronco II 1984-1990 Rear 880 mm34.6 in 936-895936895 —
IJ2986319 2-Piece Steel Ford Ecosport 2018-2019 Rear 1804 mm71.0 in 986-319986319
GN1Z-4R602-AGN1Z4R602A
GN1Z-4R602-BGN1Z4R602B
IJ2936846 2-Piece Steel Ford Edge 2008-2014
Lincoln MKX 2008 - 2015
Rear 2045 mm80.5 in 936-846936846
7T4Z-4R602-A7T4Z4R602A
DT4Z4R602A
IJ2986320 2-Piece Steel Ford Edge 2015-2016 Rear 2134 mm84.0 in 986-320986320
F2GZ-4R602-DF2GZ4R602D
F2G3-4K145-CCF2G34K145CC
F2GZ-4R602-CF2GZ4R602C
F2GZ-4R602-FF2GZ4R602F
G2GZ-4R602-CG2GZ4R602C
IJ2936891 2-Piece Steel Ford Escape 2008-2009
Mercury Mariner 2008-2009
Rear 1858 mm73.1 in 936-891936891
8L8Z4R602C
IJ2936892 2-Piece Steel Ford Escape 2008-2012
Mercury Mariner 2018-2011
Rear 1880 mm74.0 in 936-892936892
BL8Z4R602A
IJ2946175 2-Piece Steel Ford Escape 2013-2018 Rear 1950 mm76.8 in 946-175946175
CV6Z-4R602-ACV6Z4R602A
CV6Z-4R602-BCV6Z4R602B
EJ7Z-4R602-BEJ7Z4R602B
EJ7Z-4R602-DEJ7Z4R602D
IJ1938199 1-Piece Steel Ford Excursion 2000-2001
Ford F-250 1999
Ford F-250 Super Duty 1999-2004
Ford F-350 Super Duty 1999-2004
Rear 1004 mm39.5 in 938-199938199
5C3Z-4A376-A5C3Z4A376A
F81Z4A376HA
IJ1938305 1-Piece Steel Ford Excursion 2000-2003
Ford F-250/350 Super Duty 1999-2001
Front 1099 mm43.3 in 938-305938305
5C3Z4A376D
F81Z4A376MA
YC3Z4A376EA
IJ1938063 1-Piece Steel Ford Excursion 2000-2005 Front 1036 mm40.8 in 938-063938063
5C3Z-4A376-CA5C3Z4A376CA
5C3Z-4A376-NA5C3Z4A376NA
YC3Z-4A376-AAYC3Z4A376AA
YC3Z-4A376-ABYC3Z4A376AB
IJ1938074 1-Piece Steel Ford Expedition 1997-2002
Ford F-150 1997-2003
Ford F-150 Heritage 2004
Ford F-250 1997-1999
Front 912 mm35.9 in 938-074938074
F65Z4A376BA
IJ1938076 1-Piece Steel Ford Expedition 2003-2006
Ford F-150 2004-2008
Lincoln Mark LT 2006-2008
Front 880 mm34.6 in 938-076938076
2L1Z-4A376-AA2L1Z4A376AA
5L3Z-4A376-A5L3Z4A376A
IJ1946182 1-Piece Steel Ford Expedition 2003-2006 Rear 1197 mm47.1 in 946-182946182
2L1Z-4602-FA2L1Z4602FA
2L1Z-4602-FC2L1Z4602FC
4L1Z-4602-BA4L1Z4602BA
5L1Z-4602-BA5L1Z4602BA
6L1Z-4602-A6L1Z4602A
IJ1946630 1-Piece Steel Ford Expedition 2007-2012
Lincoln Navigator 2007-2012
Rear 1321 mm52.0 in 946-630946630
7L1Z-4602-A7L1Z4602A
DL1Z-4602-ADL1Z4602A
DL1Z-4602-CDL1Z4602C
IJ1938082 1-Piece Steel Ford Expedition 2007-2014
Ford F-150 2009-2014
Lincoln Mark LT 2010-2014
Lincoln Navigator 2007-2014
Front 801 mm31.5 in 938-082938082
7L1Z-4A376-A7L1Z4A376A
7L1Z-4A376-B7L1Z4A376B
AL3Z-4A376-CAL3Z4A376C
AL3Z-4A376-DAL3Z4A376D
IJ1976070 1-Piece Steel Ford Expedition 2007-2014
Lincoln Navigator 2007-2014
Rear 1623 mm63.9 in 976-070976070
7L1Z-4602-B7L1Z4602B
DL1Z-4602-BDL1Z4602B
DL1Z-4602-DDL1Z4602D
IJ2986425 2-Piece Steel Ford Expedition 2009-2014
Lincoln Navigator 2009-2014
Rear 1645 mm64.8 in 986-425986425
9L1Z-4R602-B9L1Z4R602B
9L1Z-4R602-E9L1Z4R602E
9L1Z-4R602-G9L1Z4R602G
IJ1936967 1-Piece Steel Ford Expedition 2015-2017
Lincoln Navigator 2015-2017
Rear 1344 mm52.9 in 936-967936967
FL1Z-4602-AFL1Z4602A
IJ1938818 1-Piece Steel Ford Expedition 2015-2017
Ford F-150 2011-2014
Lincoln Mark LT 2011-2014
Lincoln Navigator 2015-2017
Front 753 mm29.6 in 938-818938818
BL3Z-4A376-ABL3Z4A376A
BL3Z-4A376-BBL3Z4A376B
FL3Z4A376A
IJ1976713 1-Piece Steel Ford Expedition 2018-2019
Lincoln Navigator 2018-2019
Rear 1423 mm56.0 in 976-713976713
JL1Z-4602-AJL1Z4602A
JL1Z-4602-JJL1Z4602J
IJ1976712 1-Piece Steel Ford Expedition 2018-2022
Lincoln Navigator 2018-2022
Rear 1651 mm65.0 in 976-712976712
JL1Z-4602-BJL1Z4602B
JL1Z-4602-MJL1Z4602M
JL1Z-4602-GJL1Z4602G
IJ1938183 1-Piece Steel Ford Explorer 1993-1996
Ford Ranger 1993-1997
Front 747 mm29.4 in 938-183938183
F37Z4A376B
ZZL125500
ZZM225500
IJ1936325 1-Piece Steel Ford Explorer 1997-2001
Mercury Mountaineer 1997-2001
Front 762 mm30.0 in 936-325936325
F77Z 4A376-CBF77Z4A376CB
XL2Z-4A376-BAXL2Z4A376BA
XL2Z-4A376-BBXL2Z4A376BB
IJ1936813 1-Piece Steel Ford Explorer 1997-2001
Ford Ranger 1998-2011
Front 782 mm30.8 in 936-813936813
XL2Z-4A376-AAXL2Z4A376AA
F77Z-4A376-BAF77Z4A376BA
ZZR0-25-100ZZR025100
IJ1936327 1-Piece Steel Ford Explorer 2002-2005
Lincoln Aviator 2003-2005
Mercury Mountaineer 2002-2005
Front 724 mm28.5 in 936-327936327
1L2Z-4A376-AA1L2Z4A376AA
IJ1936530 1-Piece Steel Ford Explorer 2002-2008
Mercury Mountaineer 2002-2008
Rear 1639 mm64.5 in 936-530936530
1L2Z-4602-FA1L2Z4602FA
4L2Z-4602-BA4L2Z4602BA
7L2Z-4602-B7L2Z4602B
IJ1938800 1-Piece Steel Ford Explorer 2006
Mercury Mountaineer 2006
Front 731 mm28.8 in 938-800938800
6L2Z-4A376-AA6L2Z4A376AA
6L2Z-4A376-A6L2Z4A376A
6L2Z-4A376-B6L2Z4A376B
IJ2986335 2-Piece Steel Ford Explorer 2016-2018 Rear 2182 mm85.9 in 986-335986335
FB5Z-4R602-AFB5Z4R602A
IJ2936896 2-Piece Steel Ford Explorer Sport Trac 2016-2018 Rear 1661 mm65.4 in 936-896936896
7A2Z-4R602-D7A2Z4R602D
7A2Z-4R602-G7A2Z4R602G
7A2Z-4R602-K7A2Z4R602K
7A2Z-4R602-N7A2Z4R602N
IJ1938031 1-Piece Steel Ford F-150 1997-2003
Ford F-250 1997-1999
Lincoln Navigator 1998-2002
Front 1023 mm40.3 in 938-031938031
F75Z-4A376-BBF75Z4A376BB
IJ1946814 1-Piece Steel Ford F-150 2004-2008 Rear 1709 mm67.3 in 946-814946814
4L34-4602-KB4L344602KB
4L3Z-4602-KA4L3Z4602KA
4L3Z-4602-KB4L3Z4602KB
5L34-4602-KA5L344602KA
5L3Z-4602-KA5L3Z4602KA
IJ1946815 1-Piece Steel Ford F-150 2004-2008 Rear 1740 mm68.5 in 946-815946815
4L3Z4-602-JA4L3Z4602JA
4L3Z4-602-JB4L3Z4602JB
5L3Z4-602-JA5L3Z4602JA
IJ1946816 1-Piece Steel Ford F-150 2004-2008
Lincoln Mark LT 2006-2007
Rear 1861 mm73.3 in 946-816946816
5L3Z-4602-MA5L3Z4602MA
IJ2936802 2-Piece Steel Ford F-150 2004-2008
Ford Lobo 2006-2008
Ford Lobo 2004
Rear 2261 mm89.0 in 936-802936802
8L3Z 4R602-G8L3Z4R602G
IJ2936803 2-Piece Steel Ford F-150 2004-2008
Ford Lobo 2007-2008
Rear 2337 mm92.0 in 936-803936803
8L3Z-4R602-E8L3Z4R602E
IJ2936806 2-Piece Steel Ford F-150 2004-2008
Ford Lobo 2004-2008
Rear 2737 mm107.8 in 936-806936806
8L3Z-4R602-H8L3Z4R602H
IJ1946336 1-Piece Steel Ford F-150 2005-2008 Rear 1886 mm74.3 in 946-336946336
5L3Z-4602-AA5L3Z4602AA
IJ1946818 1-Piece Steel Ford F-150 2005-2008
Lincoln Mark LT 2006-2008
Rear 1861 mm73.3 in 946-818946818
4L3Z4602XA
4L3Z4602XB
5L3Z4602XC
7L3Z4602H
7L3Z4602K
8L3Z4602K
IJ6946805 Aluminum Ford F-150 2006-2008
Lincoln Mark LT 2007-2008
Rear 2026 mm79.8 in 946-805946805
6L3Z4602D
6L3Z4602H
7L3Z4602G
8L3Z4602G
IJ1936538 1-Piece Steel Ford F-150 2007 Rear 1855 mm73.0 in 936-538936538
7L34-4602-YA7L344602YA
4L3Z-4602-AB4L3Z4602AB
4L3Z-4602-AC4L3Z4602AC
5L3Z-4602-YA5L3Z4602YA
7L3Z-4602-J7L3Z4602J
IJ2936801 2-Piece Steel Ford F-150 2007-2008
Lincoln Mark LT 2007-2008
Rear 2309 mm90.9 in 936-801936801
7L3Z-4R602-F7L3Z4R602F
8L3Z-4R602-F8L3Z4R602F
IJ2936564 2-Piece Steel Ford F-150 2009-2010 Rear 2369 mm93.3 in 936-564936564
9L3Z-4R602-R9L3Z4R602R
9L3Z4R602RE
AL3Z-4R602-RAAL3Z4R602RA
AL3Z-4R602-RBAL3Z4R602RB
IJ2936809 2-Piece Steel Ford F-150 2009-2014
Ford Lobo 2010-2011
Rear 2325 mm91.5 in 936-809936809
9L3Z4R602L
9L3Z4R602LF
AL3Z 4R602-KBAL3Z4R602KB
AL3Z4R602KA
BL3Z4R602L
DL3Z4R602AN
DL3Z4R602L
DL3Z4R602Z
IJ2946832 2-Piece Steel Ford F-150 2009-2014 Rear 2337 mm92.0 in 946-832946832
9L3Z-4R602-GE9L3Z4R602GE
9L3Z-4R602-GF9L3Z4R602GF
AL3Z-4R602-GAAL3Z4R602GA
AL3Z-4R602-GBAL3Z4R602GB
BL3Z4R602M
DL3Z4R602AK
DL3Z4R602D
DL3Z4R602S
IJ2946385 2-Piece Steel Ford F-150 2011-2013
Lincoln Mark LT 2011-2013
Rear 1861 mm73.3 in 946-385946385
BL3Z-4R602-CBL3Z4R602C
DL3Z-4R602-NDL3Z4R602N
DL3Z-4R602-ABDL3Z4R602AB
DL3Z-4R602-ARDL3Z4R602AR
IJ2946831 2-Piece Steel Ford F-150 2011-2013
Lincoln Mark LT 2011-2013
Rear 2363 mm93.0 in 946-831946831
DL3Z-4R602-BDL3Z4R602B
DL3Z-4R602-QDL3Z4R602Q
DL3Z-4R602-AHDL3Z4R602AH
BL3Z-4R602-HBL3Z4R602H
IJ2976734 2-Piece Steel Ford F-150 2011-2013
Lincoln Mark LT 2011-2013
Rear 1925 mm75.8 in 976-734976734
BL3Z-4R602-BBL3Z4R602B
DL3Z-4R602-AADL3Z4R602AA
DL3Z-4R602-MDL3Z4R602M
DL3Z-4R602-APDL3Z4R602AP
IJ6936935 Aluminum Ford F-150 2011-2014 Rear 1994 mm78.5 in 936-935936935
BL3Z4602C
DL3Z4602E
DL3Z4602K
IJ6976742 Aluminum Ford F-150 2011-2014 Rear 2032 mm80.0 in 976-742976742
BL3Z4602B
DL3Z4602D
DL3Z4602J
IJ1976260 1-Piece Steel Ford F-150 2012-2013
Lincoln Mark LT 2012-2013
Rear 1988 mm78.3 in 976-260976260
DL3Z-4602-FDL3Z4602F
DL3Z-4602-ADL3Z4602A
DL3Z-4602-LDL3Z4602L
IJ2936931 2-Piece Steel Ford F-150 2013-2014 Rear 2407 mm94.8 in 936-931936931
BL3Z-4R602-ABL3Z4R602A
DL3Z-4R602-ADL3Z4R602A
DL3Z-4R602-AGDL3Z4R602AG
DL3Z-4R602-PDL3Z4R602P
IJ1986222 1-Piece Steel Ford F-150 2015-2017 Rear 1467 mm57.8 in 986-222986222
FL3Z-4602-AFL3Z4602A
IJ2986103 2-Piece Steel Ford F-150 2015-2017 Rear 2302 mm90.6 in 986-103986103
FL3Z-4R602-CFL3Z4R602C
FL3Z-4R602-XFL3Z4R602X
IJ6986110 Aluminum Ford F-150 2018-2019 Front 2004 mm78.9 in 986-110986110
JL3Z4602L
IJ1938802 1-Piece Steel Ford F-250 1999-2003
Ford F-350 1999-2003
Rear 1080 mm42.5 in 938-802938802
5C3Z-4A376-FA5C3Z4A376FA
5C3Z-4A376-LA5C3Z4A376LA
F81Z-4A376-NAF81Z4A376NA
F81Z-4A376-PAF81Z4A376PA
YC3Z-4A376-RAYC3Z4A376RA
YC3Z-4A376-SAYC3Z4A376SA
YC3Z-4A376-TAYC3Z4A376TA
YC3Z-4A376-UAYC3Z4A376UA
YC3Z-4A376-VAYC3Z4A376VA
YC3Z-4A376-WAYC3Z4A376WA
IJ1946836 1-Piece Steel Ford F-250 SD Pickup 1999-2002
Ford F-350 SD Pickup 1999-2002
Rear 1293 mm50.9 in 946-836946836
F81Z-4602-CNF81Z4602CN
F81Z-4602-CTGF81Z4602CTG
F81Z-4602-CXF81Z4602CX
IJ1938301 1-Piece Steel Ford F-250 SD Pickup 2005-2010
Ford F-350 SD Pickup 2005-2010
Front 994 mm39.1 in 938-301938301
5C3Z-4A376-AA5C3Z4A376AA
5C3Z-4A376-EA5C3Z4A376EA
5C3Z-4A376-G5C3Z4A376G
9C3Z-4A376-C9C3Z4A376C
F81Z-4A376-KAF81Z4A376KA
YC3Z-4A376-CAYC3Z4A376CA
IJ1938801 1-Piece Steel Ford F-250 Super Duty 2003-2010
Ford F-350 Super Duty 2003-2010
Ford F-450 Super Duty 2003-2010
Ford F-550 Super Duty (Automatic) 2003-2010
Ford F-550 Super Duty
(Manual) 2003-2004
Front 1055 mm41.5 in 938-801938801
3C3Z4A376AA
5C3Z4A376DA
5C3Z4A376F
5C3Z4A376JA
9C3Z4A376B
IJ1946840 1-Piece Steel Ford F-250 Super Duty 2011-2016
Ford F-350 Super Duty 2011-2016
Rear 1990 mm78.3 in 946-840946840
BC3Z-4602-KBC3Z4602K
BC3Z-4602-QBC3Z4602Q
BC3Z-4602-XBC3Z4602X
IJ1986440 1-Piece Steel Ford F-250 Super Duty 2011-2016
Ford F-350 Super Duty 2011-2016
Rear 1909 mm75.2 in 986-440986440
BC3Z-4602-BBC3Z4602B
IJ1938293 1-Piece Steel Ford F-250 Super Duty 2017-2019
Ford F-350 Super Duty 2017-2019
Ford F-450 Super Duty 2017-2019
Ford F-550 Super Duty 2017-2019
Front 1016 mm40.0 in 938-293938293
HC3Z-4A376-AHC3Z4A376A
HC3Z-4A376-BHC3Z4A376B
IJ1936541 1-Piece Steel Ford F-350 Super Duty 2001-2002 Rear 1417 mm55.8 in 936-541936541
F81Z4602AKB
F81Z4602AU
IJ1946311 1-Piece Steel Ford F-350 Super Duty 2005-2007 Rear 1401 mm55.2 in 946-311946311
2C7Z-4602-BA2C7Z4602BA
2C7Z-4602-BB2C7Z4602BB
IJ1938304 1-Piece Steel Ford F250/350/450/550 Super Duty 2011-2016 Front 1023 mm40.3 in 938-304938304
BC3Z4A376A
IJ2936810 2-Piece Steel Ford Five Hundred 2005-2007
Mercury Montego 2005-2007
Rear 1433 mm56.4 in 936-810936810
5F9Z-4R602-AA5F9Z4R602AA
6F9Z-4R602-A6F9Z4R602A
7F9Z-4R602-A7F9Z4R602A
IJ3936848 3-Piece Steel Ford Flex 2009-2012 Rear 2267 mm89.3 in 936-848936848
8A8Z-4R602-B8A8Z4R602B
8A8Z-4R602-A8A8Z4R602A
DA8Z-4R602-ADA8Z4R602A
FA8Z-4R602-AFA8Z4R602A
IJ2936811 2-Piece Steel Ford Fusion 2007-2012 Rear 2032 mm80.0 in 936-811936811
AE5Z-4R602-AAE5Z4R602A
7E5Z 4R602-A7E5Z4R602A
IJ2986658 2-Piece Steel Ford Fusion MK5 13 Rear 2137 mm84.1 in 986-658986658
DG9Z-4R602-ADG9Z4R602A
IJ1946812 1-Piece Steel Ford Mustang 2011-2014 Rear 1471 mm57.9 in 946-812946812
BR3Z-4602-ABR3Z4602A
BR3Z-4602-BBR3Z4602B
BR3Z-4602-CBR3Z4602C
IJ1936286 1-Piece Steel Ford Ranger 2004-2011
Ford Ranger 2002
Mazda B2300 2003-2004
Mazda B2500 1998-2000
Rear 762 mm30.0 in 936-286936286
1F6125100
1F7125100
2L544602AA
2L5Z4602AA
5L5Z4602PA
9210651526M
9210656002
9234361526M
F87A4602PB
IJ2936847 2-Piece Steel Ford Taurus 2008
Ford Taurus X 2008
Mercury Sable 2008
Rear 2147 mm84.5 in 936-847936847
8G1Z-4R602-A8G1Z4R602A
8G1Z-4R602-B8G1Z4R602B
FG1Z4R602A
IJ2976947 2-Piece Steel Ford Thunderbird 2002-2005 Rear 1290 mm50.8 in 976-947976947
2W6Z-4R602-AA2W6Z4R602AA
3W6Z-4R602-AA3W6Z4R602AA
3W6Z-4R602-AB3W6Z4R602AB
IJ3986267 3-Piece Steel Ford Transit 2015-2017 Rear 2442 mm96.1 in 986-267986267
CK4Z-4R602-LCK4Z4R602L
CK4Z-4R602-YCK4Z4R602Y
CK4Z-4R602-BACK4Z4R602BA
CK4Z-4R602-BVCK4Z4R602BV
CK4Z-4R602-ADCK4Z4R602AD
Distributors and importers: send us the IJE, Dorman or OE number to request a quote. Request a quote · Search all makes

Dorman is a trademark of Dorman Products, Inc. Vehicle manufacturer names, model names and OE part numbers are used for identification and cross-reference only. YI-JEONG Industrial is not affiliated with or endorsed by Dorman Products or any vehicle manufacturer. Please confirm fitment with the OE number or a sample before ordering.

TOP
